4 Axis NEMA34 2Phase 60VAC 5.6A 4.5N.m Closed Loop Stepper Kit Driver+Motor+Controller+60VAC Transformer for CNC Motion Control

Model:  4SK-CL5730+55V



1. Shipping list



4 PCS Drive

HBS860H

4 PCS Motor

57HBS45

2PCS Power Supply

600W 60V AC

1 PCS 3.5 inch color display controller

TC5540V

4 PCS Encoder Cables

4 PCS Power cables

3-meter

2. Features

HBS860Huses advanced motor control DSP chip and vector loop control technology

High accurate, highly reliable low noise and little vibration

With 3.5 inch color screen, English panel display;

Free chooses the default interface, with configuration function;

Easy to operate and configurate;

Enough power supply for the motor

The accessories are completely, one shop get all parts, convenient and cost-effective.

We provide technical support



3. Technical parameters

TC5540V Controller

HTB1UogUeOAnBKNjSZFvq6yTKXXaY



Drive parameters

Model

HBS860H

Type

DSP Closed loop stepper drive

maximum peak current

8A

Impulse response frequency

200KHz

Micro-stepping driver

200~51200ppr

Voltage

20~80VAC/DC30-110V

Protective function

Over voltage, over current, tracking error, overproof

Signal input

Support PUL/DIR and CW/CCW modes (difference)

Compatible 5~24V signal (Don\'t need a resistor)

Advantage

no step to lose, Low noise, little vibration and high efficiency, low heat

Continuous overload

Output an alarm signal

Type of cooling

Air-cooling



Min

Typical

Max

Unit

Output Current

-

-

8

A

Input Voltage

20

70

75

VAC

30



110V

VDC

Logic Signal Current

7

10

16

mA

Pulse input frequency

-

200

-

kHz

Isolation Voltage

500





Mohm



Motor electric parameter



Model

86HBS45

Step angle/phase

1.8 degree

Rated voltage/current

2.24V/5.6A

resistance

0.4ohm

Inductance

2.6mH

Hold torque

4.5NM

Max.  Speed

1000RPM

Encoder

1000line

Class of insulation

B

Rotor inertia

1400 g.cm2

4SK-CL8645+55V (4)

Power Supply

Model

S-600-60

Output voltage

60Vdc

Max output Power

600W

Max output current

10A

AC input voltage range

0-240V  50hz

(110V Optional, different price)

4. Pictures and drawings

4SK-CL5730+55V (1)4SK-CL5730+55V (2)4SK-CL5730+55V (3)



5. Applications



Closed loop steppers with good performance in short-distance and short-time stop, fast start-stop and zero-speed stable stop, it is widely used in the field of desktop CNC routers, small CNC mills, laser cutters / engravers, dental mills, electronic assembly & inspection equipments, labeling equipments, pick & place machines, X-Y tables, scientific instruments.
